Workshop Facility

GS has four established Workshops in Shuaiba Industrial Area, covering the area of 44,000 Square Meters.

Workshop 1(Pressure Vessel Fabrication)

GS currently operates vessel fabrication facilities at Shuaiba industrial area. The details of the shop are as listed below:

  • Location : Shuaiba East, Kuwait
  • Shelter Size & Area : 66 Mtr x 35 Mtr = 2310 Sqm.
  • Open Storage Paved Area : 60 Mtr x 27 Mtr = 1620 Sqm.
  • Vessel fabrication Capacity : Dia - 3.5 Mtr x Length - 15 Mtr x Maximum - 30mm Thick.

Workshop 3(Steel Support Fabrication)

GS also operates a fabrication facility at Shuaiba industrial area for structural steel and support fabrication. The details of the shop are as below:

  • Location : Shuaiba East, Kuwait
  • Shelter Size & Area : 100 Mtr x 65 Mtr = 6500 Sqm.
  • Capacity : 150Ton / Month

Workshop 2(Piping Fabrication)

GS currently operates piping fabrication facilities at Shuaiba industrial area. The details of the shop are as listed below

  • Location : Shuaiba East, Kuwait
  • Shelter Size & Area : 85 Mtr x 46 Mtr = 3910 Sqm.
  • Open Storage Paved Area : 95 Mtr x 27 Mtr = 2565 Sqm.
  • Capacity : 900-1500 Dia Inch/per Day * (* The capacity depends on spool size, thickness and MOC)

Workshop 4(Spool Fabrication Shop)

GS currently operates piping fabrication facilities at Shuaiba industrial area. The details of the shop are as listed below

  • Location : Shuaiba East, Kuwait
  • Shelter Size & Area : 45 Mtr x 20 Mtr = 900 Sqm.
  • Open Storage Paved Area : 95 Mtr x 27 Mtr = 2565 Sqm.
  • Capacity : 600-800 Dia Inch/per Day * (* The capacity depends on spool size, thickness and MOC)

Gulf Spic Layout Legend Details

1 - Pressure Vessel & Pig Trap Fabrication Shop
2 - Piping Fabrication Shop
3 - Blasting & Painting Area
4 - Area for Raw Material Storage and Spool Storage
5 – PMO Service Office Area
6 – Material Storage Area - Open
7 – Material storage area - Covered
8 – Scaffolding Storage Area
9 – Area For Heavy Equipment Parking
Vessel Fabrication
Spool Fabrication & Hydrotest
Steel Fabrication
Sand Blasting & Painting
Heat Exchanger Retubing

Facility Details – Workshop-1&2

SL

EQUIPMENT

CAPACITY/RANGE

MANUFACTURER

QTY

VESSEL & PIPE SPOOL FABRICATION SHOP

1

PIPE PROFILE CUTTING MACHINE (SPC 1000)

DIA-48mm to 1020mm

HGG

1

2

CNC PLATE CUTTING MACHINE

Thick-Up to 50 mm

AJAN

1

3

SUBMERGED ARC WELDING MACHINE

DIA-6" to 36"

ESAB

3

4

ROLLING MACHINE(CNC MACHINE)

(Dia 600 mm ,

Width - 3 Mtr X Thk 32 mm)

DAVI

1

5

WELDING RECTIFIER (IDEAL ARC R3R 500-I)

500 A

LINCOLN ELECTRIC

22

6

WELDING RECTIFIER

300A

INVERTEC 300TPX

37

7

WELDING RECTIFIER

400A

INVERTEC 400TPX

13

8

EOT CRANE

15 TON

MORRIS

1

9

EOT CRANE

5 TON

HI-TECH INDUSTRIES

10

10

A-FRAME GANTRY CRANE

5 TON

HI-TECH INDUSTRIES

2

PAINTING FACILITY

1

BLASTING BOOTH

SURFEX – 128 Sq.m

1

2

BLASTING MACHINE

EUROBLAST -200 L

7

3

BLASTING MACHINE

EUROBLAST – 40L

2

4

AIRLESS SPRAYER

GRACO

6


Facility Details – Workshop-3

SL

DESCRIPTION

MAKE

QTY

1

HYDRAULIC PUNCHING MACHINE

SAHINLER(HPM-115)

1

2

CNC HYDRAULIC PRESS BRAKE

ERMAKSAN

1

3

HYDRAULIC CNC PLATE SHEARING MACHINE

ERMAKSAN

1

4

ELECTRO HYDRAULIC PRESSING MACHINE

ACHYDRAULIC

1

5

WELDING MACHINES

LINCOL ELECTRIC

15

6

EOT CRANE

SAREET-10 T

1

7

A FRAME GANTRY CRANE(5T-14.5m SPAN)

VERTEX

2

8

PORTABLE HYDRALIC PUNCHING MACHINE

PROMOTECH

3

9

LATHE

97714

1

10

BENCH DRILLING MACHINE

DELTA

1

11

EXCEL RADIAL DRILLING MACHINE

EXCEL

1
